Volvo S60/V60 19+ Innovative Series Coilover
Volvo S60/V60 19+ Innovative Series Coilover
VV11-IS
🔴 Built To Order (2-4 Weeks)
Couldn't load pickup availability
Need help? Live Chat or Email!
This coilover suspension upgrade is designed to achieve a perfect balance of street comfort and increased performance. This suspension system allows you to easily adjust your ride height while improving handling performance of your car.
Our patented scaled system design allows easier and more precise adjustment and ensures equal height on each corner. Each shock is equipped with 24 levels of dampening adjustment to fine-tune the valving efficiency.
The Part : VV11-IS coilover shocks are handcrafted and assembled to your specs at SCALE facilities.
This car use leaf spring on the rear. The suspension is designed to match the rear leaf spring with the leaf spring spacer removed at lowest setting. We also include washer to adjust rear ride height if needed.
This double-wishbone front configuration does not allow the use of a camber plate, as the shock is not directly connected to the wheel. If additional camber adjustment is needed after lowering your car, some specialized company may offer adjustable control arm.
On this rear multilink configuration, the shock have no direct impact on wheel alignment so the car only has OEM alignment adjustment. If you need more adjustments, you can check if a specialized company offers adjustable control arms.
Our mono-tube shock absorber are using high-quality CNC piston valves, synthetic oil and high-pressure nitrogen gas contained within one tube.
As this application uses a specifically shaped spring, only the regular version is available and the custom spring rate or Swift spring upgrade only applies to the linear spring of this application. The swift upgrade price is for 2 springs only.
Technical Specs
| Make | Volvo |
|---|---|
| Model | S60 and V60 |
| Year | 2019, 2020, 2021, 2022, 2023, and 2024 |
| Front Suspension | Double Wishbone |
| Rear Suspension | N/A |
| Number of Valves | 24 |
| Aluminum Type | 6061-T6 CNC-Forged |
| Body Diameter | M52X1.5 |
| Internal Design | Monotube |
| Shock Oil Type | Synthetic Shock Oil |
| Pressurized Charge | High Pressure Nitrogen Gas |
| Assembly | No Welding Required, Rebuildable |
Very well built product, great engineering. No issues with the install except for some frozen bolts. Lowered about 1.5 inches now, but will adjust again in a few weeks of driving. What a fantastic difference in handling. Handles better than my S2000 which is like a go cart on the street. Dampening adjustments are precise and you can feel the difference in the settings (I made adjusts of 3 turns then drove the car). Almost no body lean on transitions and the car just plants in the corners. Paired with new wheels and Continental S02’s, this suspension system is just awesome. Would highly recommend to anyone who wants to take their Volvo S60 to the next level. I attached pics of before and after the install. I like the quality and results so much I am getting the same Innovative suspension in the spring for my 2022 Maxima!! Well done Scale Suspension!!!
Thank you for your glowing review! We are thrilled to hear that you are enjoying the handling improvements and precise dampening adjustments of our Innovative Series Coilover on your Volvo S60. We are also happy to hear that you plan on getting the same suspension for your Maxima in the future. We appreciate your support and look forward to providing you with high-quality products again in the future. Happy driving!
Are these compatible with the 2024 S60 B5 Core FWD as well?
Hello! Yes they are! Direct bolt up.
I'm pretty new to this, but I learned enough to know this is a better solution than lowering springs, especially for my '24 S60 with barely 3k miles. I'm just curious about this option you have for your coilovers: Spring Upgrade Options.
What would be considered Default spring rate, what is Custom, and finally, what would a Swift Sitting upgrade do compared to the default and the custom options?
Default spring rate is going to about 15% stiffer then OEM. For the best comfort we would recommend sticking with the default.
Swift Springs will provide a slightly better ride quality and a more consistant rebound due to having less total coils.
Will these fit a 2019 Volvo s60 T8 PHEV?
Hello! These coilovers will properly work on your vehicle.
